New production of the clean Clean X1 block, modified with some news according to the first series.
Made in 6061 T6 aluminum with mechanisms in 7075 T6. 120mm length tube, completely redesigned.
Compatible with integrated, conical, 1 1/8 "in the upper part, 1/5" in the inferior.
Executives in the main tubes rediscovered a good rigidity and a weight and weight gains in the union with a direction of control for advancing rigidities and other problems.
Design for 116mm translucent shoes. Post Mount integrated system integrated on a single floor with a hard drive for rigid users The only way of disco, keeping a small gorilla of the Union between the different tubes will follow the line of the first series.
Median tensile system with integrated chain. Blue color with graphics Clean Trials in red and white.
Frame: Clean X1. Aluminum 6061 T6 + 7075 T6
Fork: Clean X2. Aluminum 7005 T6. HS or PM
Handlebar: Clean ALU. 103mm height
Grips: Clean extra-fine foam
Stem: Clean 150x35º (970mm 135x25)
Headset: Clean Tapered. Super light. semi integrated Hubs: Clean Expert. 100mm front, 116mm rear
Brakes: Hope Tech 3
Discs: Clean RS 160mm + 162.5mm
Bottom Bracket: Clean ISIS 128mm
Pedals: Clean Single Cage. Chain: KMC 610HX
Tensioner: Clean Integrated. 7075 CNC. 11T plastic wheels
Rims: Clean Spokes: 1.8 Black
Nipples: 16g Aluminum Red
Freewheel: 108.9. 18T Fixed
Gear: Clean 12T (970mm 14t)
Front tire: Koala 20” Rear tire: Koala 19”
Front tube: Maxxis Extralight
Rear tube: Maxxis Extralight
Overall length: 1005mm
Bottom bracket height: +87mm
Back base: 350mm
Steering angle: 72º
